ID # 19413480

Wacker Neuson BS50-2plus, BS60-2plus, BS70-2plus

  • Wacker Neuson BS50 2plus, BS60 2plus, BS70 2plus
  • Wacker Neuson BS50 2plus, BS60 2plus, BS70 2plus
  • Wacker Neuson BS50 2plus, BS60 2plus, BS70 2plus
  • Wacker Neuson BS50 2plus, BS60 2plus, BS70 2plus
  • Wacker Neuson BS50 2plus, BS60 2plus, BS70 2plus
  • Wacker Neuson BS50 2plus, BS60 2plus, BS70 2plus
  • Wacker Neuson BS50 2plus, BS60 2plus, BS70 2plus
  • Wacker Neuson BS50 2plus, BS60 2plus, BS70 2plus
  • Wacker Neuson BS50 2plus, BS60 2plus, BS70 2plus
Videos
Call for Price
 Get a Quote  Get Financed  Value a Trade  Contact Us  Book a Demo   Get Directions  Print
Overview

BS50-2plus, BS60-2plus, BS70-2plus - Two-stroke rammers plus oil-injection

The unique Plus rammer series provides all the advantages of the classic two-stroke rammer, plus the convenience of a no-mix system. The two separate tanks for fuel and two-cycle oil eliminate premixing, and automatically provides the correct mix for long, clean running times. The Plus series rammers are available in three weight classes and are ideal for compaction of cohesive and mixed soil in trenches and other confined areas. The low center of gravity provides high performance and stability during operation.
  • Lean fuel-to-oil ratio and large oil tank allow for up to 120 hours of run time
  • Optimized guide handle reduces hand-arm vibration and improves operator comfort
  • Comfortable operation with auto-choke and only one lever for idling, starting and stopping
  • Automatic shutdown after 10 minutes if left idling reduces emissions or when starting with an empty oil tank
  • A unique four-stage air filtration provides a virtually dust-free engine for longer life and improved durability. The system includes a last chance filter that protects the engine during air filter maintenance
Specifications
Model
BS50-2plus, BS60-2plus, BS70-2plus
Category Name
Industrial
Year
2022
Sale Type
New
Manufacturer
Wacker Neuson
description

Wacker Neuson BS50 2plus, BS60 2plus, BS70 2plus Emission values of gasoline rammers

  • Specially designed catalytic converter offers emissions that meet all current regulatory requirements.

Wacker Neuson BS50 2plus, BS60 2plus, BS70 2plus Exclusive engine design

  • Specifically designed for use in soil compaction
  • Fewer moving parts reduces maintenance and promotes longer life

Wacker Neuson BS50 2plus, BS60 2plus, BS70 2plus Hour meter

  • For easy tracking of time and maintenance intervals
  • Standard on all models

Wacker Neuson BS50 2plus, BS60 2plus, BS70 2plus 4-stage air filter system

  • Very good filter performance thanks to 4-fold air filter (consisting of cyclone filter, paper lamella filter and double foam filter)
  • Clean intake air ensures optimum engine performance
  • Long service intervals due to high filter capacity

Wacker Neuson BS50 2plus, BS60 2plus, BS70 2plus Easy transport

  • Large and flexible lift point
  • Easy loading and stowing by transport rollers on the handle

Wacker Neuson BS50 2plus, BS60 2plus, BS70 2plus Comfortable operation with auto-choke

  • Only one lever for idling, starting and stopping
bs50-2plus, bs60-2plus, bs70-2plus technical specifications

Metric

  BS50-2plus 6'' BS50-2plus 11'' BS60-2plus 11'' BS70-2plus 11''

Operating data
Operating weight  kg 56 59 66 74
Ramming shoe size (WxL) * mm 150 x 340 280 x 340 280 x 340 280 x 340
L x W x H  mm 673 x 343 x 940 673 x 343 x 940 673 x 343 x 965 673 x 343 x 965
Percussion rate max. blows/min 700 700 700 700
Stroke on the ramming shoe mm 43 64 65 65
Impact force  kN 16 16 18 20

Engine / Motor
Engine / Motor type  Air-cooled, single cylinder, two-cycle gasoline engine Air-cooled, single cylinder, two-cycle gasoline engine Air-cooled, single cylinder, two-cycle gasoline engine Air-cooled, single cylinder, two-cycle gasoline engine
Engine / Motor manufacturer  Wacker Neuson Wacker Neuson Wacker Neuson Wacker Neuson
Engine / Motor  WM80 WM80 WM80 WM80
Displacement  cm³ 80 80 80 80
Fuel consumption  l/h 1 1 1.2 1.4
Operating performance (DIN ISO 3046-1) kW 1.7 1.7 1.7 1.7
at rpm  rpm 4,400 4,400 4,400 4,400
Fuel tank capacity  l 3 3 3 3
Gasoline / oil mixture  100:1 100:1 100:1 100:1
CO2 (NRSC) ** g/kWh 1,113 1,113 1,113 1,11


 Imperial

  BS50-2plus 6'' BS50-2plus 11'' BS60-2plus 11'' BS70-2plus 11''

Operating data
Operating weight  lb 123 130 146 163
Ramming shoe size (WxL) * in 5.9 x 13.4 5.9 x 13.4 9.8 x 13.4 9.8 x 13.4
L x W x H  in 26.52 x 13.51 x 37 26.5 x 13.5 x 37 26.5 x 13.5 x 38 26.5 x 13.5 x 38
Percussion rate max. blows/min 700 700 700 700
Stroke on the ramming shoe in 1.7 2.5 2.6 2.6
Impact force  lbf 3,597 3,597 4,047 4,496

Engine / Motor
Engine / Motor type  Air-cooled, single cylinder, two-cycle gasoline engine Air-cooled, single cylinder, two-cycle gasoline engine Air-cooled, single cylinder, two-cycle gasoline engine Air-cooled, single cylinder, two-cycle gasoline engine
Engine / Motor manufacturer  Wacker Neuson Wacker Neuson Wacker Neuson Wacker Neuson
Engine / Motor  WM80 WM80 WM80 WM80
Displacement  in³ 4.9 4.9 4.9 4.9
Fuel consumption  US gal/h 0.26 0.26 0.32 0.37
Operating performance (DIN ISO 3046-1) hp 2.3 2.3 2.3 2.3
at rpm  rpm 4,400 4,400 4,400 4,400
Fuel tank capacity  US gal 0.8 0.8 0.8 0.8
Gasoline / oil mixture  100:1 100:1 100:1 100:1
CO2 (NRSC) ** g/kW-hr 1,113 1,113 1,113 1,113
