TYM Tractors BL350 Front-End Loader

Specifications

Model	BL350	Category Name	Lawn / Garden	Year	2025
Sale Type	New	Manufacturer	TYM Tractors	Odometer	km
Lift Height	117.5 in. / 2984 mm	Lift Capacity	3437 lb / 1559 kgf	Bucket Capacity	9.5 cu. ft / 0.27 cu. m
Price	Contact for price CAD

Description

BL350
Front-End Loader
The BL350 front-end loader takes advantage of the power and durability of TYM 5835 tractors. Ideal for tasks that require more strength, the BL350 front-end loader can help you get your tasks done more efficiently.

Built for durable performance and excellent dig capabilities, the BL350 front-end loader is designed to help you accomplish more without compromising stability and safety. With a self-leveling feature in place and impressive boom raising and lowering times, you can focus on the task at hand and get more things done quickly. Engineered to deliver impressive dig depth and maximum rollback angles, the BL350 front-end loader is ideal for more heavy-duty applications.

CAPACITIES & REACH

Lift_height

117.5 in. (2984 mm)

Digging_depth

4.7 in. (120 mm)

Lift_capacity

3437 lb (1559 kgf)

Self_leveling

Bucket_capacity

9.5 cu. ft (0.27 cu. m)

Max._dump_angle

55°

Max._rollback_angle

41°

Reach_with_bucket_on_ground

76.9 in. (1952 mm)

Clearance_with_bucket_dumped

89.6 in. (2275 mm)

Reach_at_maximum_lift_height

21.3 in. (541 mm)

Max._lift_height_under_level_bucket

108.9 in. (2766 mm)

Bucket_rollback_force_at_ground_line

4032 lb (1829 kgf)

Relief_valve_setting_(Loader_control_valve)

2489 psi (175 kg/sq. cm)

Breakout_force_at_ground_level,_pivot_points

4742 lb (2151 kgf)

DIMENSIONS & WEIGHTS

Lift_cylinder

2.6X1.4 in. (65X35 mm)

Bucket_cylinder

2.4X1.4 in. (60X35 mm)

Height_of_Attachment

20.9 in. (530 mm)

Weight_of_bucket_(3)

251 lb (114 kg)

Loader_total_weight_(1+2+3)

1300 lb (590 kg)

Weight_of_mounting_frame_(2)

334 lb (151 kg)

Overall_height_in_carry_position

52.1 in. (1324 mm)

Attachment_used_for_specification

72 in. (1830 mm)

Length_of_Attachment_(to_pivot_point)

28.2 in. (690 mm)

Weight_of_boom_&_quick_attach_mechanism_(1)

717 lb (325 kg)

Depth_of_Attachment_(to_the_back_of_the_inner_shell)

20.9 in. (530 mm)

CYCLE TIMES

Boom_raising_time

5.2 sec

Boom_lowering_time

3.7 sec

Bucket_dumping_time

3.5 sec

Bucket_rollback_time

2.3 sec
